| Property | Value |
| Working Temperature | -30 °C |
| Enviroment temperature | 50 °C |
| Total el. power | 480 W |
| Typical Power Voltage (power supply) | 24 V |
| Dimming method | PWM |
| Electrical protection | Short circuit protection, OverPower protection |
| Minimum Voltage | 5 V |
| Case | Enclosed |
| IP degree | IP20 |
| Memory | Yes |
| IN/OUT terminals | Terminal block |
| Input Voltage (power supply) | DC CV |
| Output current | 20000 mA |
| No. of output channels | 4 |
| Dimming system | RF |
| Remote Controll | RF |
| Certificates | CE, RoHS |
| Max. allowed input Voltage | 24 V |
| Range | 30 m |
