| Property | Value |
| Input Voltage (power supply) | DC CV |
| Output current | 8000 mA |
| No. of output channels | 2 |
| Dimming system | DMX |
| Programmable | Yes |
| Certificates | UL, CE, CB, RoHS |
| Case | Enclosed |
| IP degree | IP20 |
| IN/OUT terminals | Terminal block |
| Minimum Voltage | 12 V |
| Electrical protection | Short circuit protection, Over Voltage protection |
| Total el. power | 200 W |
| Typical Power Voltage (power supply) | 24 V |
| Enviroment temperature | -50 °C |
| Working Temperature | -20 °C |
| Max. allowed input Voltage | 28 V |
