| Property | Value |
| Output Voltage | 24 V |
| Input Voltage (power supply) | AC |
| Output current | 1500 mA |
| Efficiency | 85 % |
| No. of output channels | 1 |
| Changeable output parameter | No |
| Certificates | CE, CB |
| PFC filter PFC filters significantly reduces the electromagnatic interference and prolongs electronic devices | No |
| Case | Enclosed |
| IP degree | IP20 |
| IN/OUT terminals | Cable In / OUT |
| Expected Lifetime Expected lifetime (L70/B10) extrapolated from LM80 data @10KHod. For LED components like LED strips, LED modules etc. are data valid with additional Heat sinking (@typ. working temperature. | 35000 Hod |
| Minimum Voltage | 90 V |
| Electrical protection | Inrush current protection, Short circuit protection, Over Voltage protection, OverPower protection |
| Total el. power | 36 W |
| Typical Power Voltage (power supply) | 230 V |
| Enviroment temperature | 65 °C |
| Regulation / Controll | Cable |
| Installation typology | Surface, Box |
| Working Temperature | -30 °C |
| Max. allowed input Voltage | 264 V |
