Programovateľné pomocou softvéru Tuner4TRONIC
| Property | Value |
| Input Voltage (power supply) | AC |
| Output current | 800 mA |
| Efficiency | 90 % |
| No. of output channels | 1 |
| Changeable output parameter | Voltage, Current, No, Power |
| Dimming system | 0-10V |
| Programmable | Yes |
| Certificates | UL, CE, CB, SELV, F, MM, Zhaga compliant, Rozšírená záruka, Vysoko-teplotné testy, Testy slaného prostredia, Testy UV žiarenia, RoHS |
| PFC filter PFC filters significantly reduces the electromagnatic interference and prolongs electronic devices | Yes, No |
| Case | Enclosed |
| IP degree | IP64 |
| IN/OUT terminals | Cable In / OUT |
| Expected Lifetime Expected lifetime (L70/B10) extrapolated from LM80 data @10KHod. For LED components like LED strips, LED modules etc. are data valid with additional Heat sinking (@typ. working temperature. | 80000 Hod |
| Minimum Voltage | 120 V |
| Electrical protection | External NTC thermistor, Polarity protection, Inrush current protection, Over temperature protection, ESD protection <2KV, Short circuit protection, Over Voltage protection, OverPower protection, ConstantPower, Constant Current |
| Total el. power | 100 W |
| Typical Power Voltage (power supply) | 230 V |
| Enviroment temperature | -40 °C |
| Power factor | 0,95 |
| Working Temperature | 55 °C |
| Max. allowed input Voltage | 277 V |
| Max. current | 350 mA |
