Property | Value |
Minimum Voltage | 21,3 V |
Product optionally produced in colour We are able to produce your selected design, in the following colour / spectral properties. | -W922, -CRISPCOLOR-W940, -SUNLIKE-W940, -W927, -W850, -CRISPCOLOR-W927, -SUPERCOLOR-MINT, -SUPERCOLOR-LIME, -SUNLIKE-W957, -GROW-PURPLE-2B5, -UVA405, -UVB385, -FRESHFOCUS-MARBLEDMEAT, -W822, -W827, -W930, -W840, -W965, -SUNLIKE-W927, -W945, -GROW-WHITE, -SUPERCOLOR-ROYALBLUE, -W935, -W865, -UVC275, -FRESHFOCUS-PRODUCE, -SUPERCOLOR-DEEPRED, -SUNLIKE-W930, -GROW-PURPLE-12B5, -GROW-PURPLE-25B, -SUPERCOLOR-RED, -SUPERCOLOR-PCAMBER, -W830, -CRISPCOLOR-W935, -W818, -FRESHFOCUS-FISH, -FRESHFOCUS-BREAD, -CRISPCOLOR-W950, -W845, -W857, -SUPERCOLOR-BLUE, -UVB305, -SUPERCOLOR-GREEN, -SUPERCOLOR-CYAN, -W950, -W957, -FRESHFOCUS-REDMEAT, -CRISPCOLOR-W930, -SUPERCOLOR-REDORANGE, -SUPERCOLOR-FARRED, -W835, -SUNLIKE-W950, -W940 |
Viewing angle | 120 ° |
Luminous flux | 2000 Lm |
LED chip manufacturer | Osram |
Cuttability | 100 mm |
Expected Lifetime Expected lifetime (L70/B10) extrapolated from LM80 data @10KHod. For LED components like LED strips, LED modules etc. are data valid with additional Heat sinking (@typ. working temperature. | 80000 Hod |
Light efficacy | 2000 Lm |
Max. Length when feed from 1 side | 6,5 m |
Features / Additional advantages | Inštalácia nalepením, Negatívny teplotný koeficient, Skrátenie sekcie LED Pásu, Skracovacie pady, Príprava na SYSCON, Prúdové drivre (CC IC), ESD ochrana |
Typical Power Voltage (power supply) | 24 V |
Dĺžka LED pásu na rolke | 10 m |
Minimum number of LEDs in shortened semgent MASTER LED strips has advantage to shorten the last segment to different number than standard 6 or 7. After shortening the last segment the SP solder shortening pad should be soldered with tiny amount of solder. | 4 |
Max. power Voltage | 25 V |
No. of LEDs/m | 70 ks |
Input Voltage (power supply) | DC CV |
Light type | SWW-Super Warm white |
LED package type | 2835 |
IP degree | IP20 |
Constant Current Drivers | Yes |
Dimming method | PWM |
Enviroment temperature | 50 °C |
Lx per meter | 573 Lx |
Total el. power | 15,2 W |
Colour rendering index CRI | 85 |
Colour temperature (primary light source) Correlated Colour Temperature CCT (K) of primary light source : is basically a specific numerical measurable definition of light colour of White spectrum according to black body curve (for example 2700K is Warm white Incandescent light, 3000K is wartm white too, but rather of halogene spectrum, but slightly more coldish etc. | 2200 K |
Max. current allowed | 6300 ma |
LED axial distance | 14,28 mm |
Max. Length @ power (Utyp2) | 10 m |
Počet BINov LED na výrobku Presnosť BINovania LED ovplivňuje kvalitu osvetlenia - ak bude výrobok osadený s LED, ktoré pochádzajú z rôznych BINov, je veľká šanca že napr. pri homogénnom/difúznom osvetlení budú jednotlivé rozdielnosti viditeľné - toto sa 10x znásobuje pri zalievaní. | 1 |
Temperature increase in working condition Temperature increase caused by el. device heat up while working in normall operation. | 44 °C |
Certificates | CE, Rozšírená záruka, Vysoko-teplotné testy, Testy UV žiarenia |
PCB width | 10 mm |
Current per 1 LED | 63 mA |
